<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "http://www.web3d.org/specifications/x3d-3.0.dtd">
<X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' http://www.web3d.org/specifications/x3d-3.0.xsd '>
<head>
<meta name='title' content='AftSuperstructure.x3d'/>
<meta name='description' content='DDG-51 Flight IIA Arleigh Burke aft superstructure'/>
<meta name='creator' content='LT Joe Sears, USN'/>
<meta name='created' content='21 July 2003'/>
<meta name='modified' content='14 January 2014'/>
<meta name='reference' content=' http://combatindex.com/store/3d '/>
<meta name='drawing' content=' http://www.fas.org/man/dod-101/sys/ship/ddg-51.htm '/>
<meta name='generator' content='X3D-Edit 3.2, https://savage.nps.edu/X3D-Edit'/>
<meta name='identifier' content=' https://savage.nps.edu/Savage/ShipsMilitary/DDG-51FlightIIA-UnitedStates/AftSuperstructure.x3d '/>
<meta name='license' content=' ../../license.html'/>
</head>
<!-- -->
<Scene>
<Group DEF='SuperstructureAft'>
<Group DEF='AFT01'>
<Transform translation='0 6 -45'>
<Shape>
<Extrusion crossSection='-7 0 -6 3.55 4 3.55 5 0 -7 0' orientation='0 0 0 0 0 0 0 0 1 0 0 .2' scale='1.427 1 1 1 1 1.02' solid='false' spine='0 0 0 0 0 -2 0 0 -27'/>
<Appearance DEF='HazeGray'>
<Material specularColor='.4 .4 .4'/>
</Appearance>
</Shape>
</Transform>
<Transform DEF='Aft01AftAdjointoHanger' translation='0 6 -45'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion ccw='false' crossSection='5 0 4.3 3.55 0 3.55 0 0 5 0' scale='2 1 1 1' spine='0 0 0 0 0 -2'/>
</Shape>
</Transform>
<Transform DEF='Aft01NonSkid' translation='0 9.58 -45'>
<Shape>
<Appearance> </Appearance>
<Extrusion creaseAngle='.85' crossSection='-6 0 4 0 4 -.01 -6 -.01 -6 0' scale='1.427 1 1 1 1 1' spine='0 0 0 0 0 -2 0 0 -26.3'/>
</Shape>
</Transform>
<Transform DEF='Aft01AftAdjoinToHangerNonSkid' translation='0 9.58 -45'>
<Shape>
<Appearance>
<ImageTexture USE='NONSKID'/>
</Appearance>
<Extrusion creaseAngle='.85' crossSection='4.3 0 4.3 -.01 0 -.01 0 0 4.3 0' scale='2 1 1 1' spine='0 0 0 0 0 -2'/>
</Shape>
</Transform>
</Group>
<Group DEF='AFT02'>
<Transform translation='0 9.55 -48.305'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion crossSection='-3.5 -.07 -3.15 1.5 3.15 1.5 3.5 -.07 -3.5 -.07' orientation='0 0 0 0 1 0 0 .2' scale='.75 1 1 1.02' solid='false' spine='0 0 0 0 0 -23'/>
</Shape>
</Transform>
<Transform DEF='Aft02NonSkid' translation='0 11.075 -48.3'>
<Shape>
<Appearance>
<ImageTexture USE='NONSKID'/>
</Appearance>
<Extrusion creaseAngle='.85' crossSection='3.15 0 -3.15 0 -3.15 -.01 3.15 -.01 3.15 0' scale='.75 1 1 1' spine='0 0 0 0 0 -22.7'/>
</Shape>
</Transform>
<Transform rotation='1 0 0 -1.57' scale='.75 .75 .75' translation='3 2.75 -111'> </Transform>
</Group>
<Group DEF='AFT03'>
<Transform translation='0 11.05 -52'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion crossSection='-3.15 -.07 -2.65 2.5 2.65 2.5 3.15 -.07 -3.15 -.07' orientation='1 0 0 -.2 1 0 0 .2' scale='.80 1 1 1.02' solid='false' spine='0 0 0 0 0 -19'/>
</Shape>
</Transform>
<Transform DEF='Aft03NonSkid' translation='0 13.56 -52.5'>
<Shape>
<Appearance>
<ImageTexture USE='NONSKID'/>
</Appearance>
<Extrusion creaseAngle='.85' crossSection='2.65 0 -2.65 0 -2.65 -.01 2.65 -.01 2.65 0' scale='.80 1 1 1' spine='0 0 0 0 0 -18'/>
</Shape>
</Transform>
<Transform translation='0 15.25 -54'> </Transform>
</Group>
<Group DEF='AFT04'>
<Transform translation='0 13.55 -55.5'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion crossSection='-2.65 -.07 -2.3 2 2.3 2 2.65 -.07 -2.65 -.07' orientation='1 0 0 -.2 1 0 0 .2' scale='.84 1 1 1.02' solid='false' spine='0 0 0 0 0 -15'/>
</Shape>
</Transform>
<Transform DEF='Aft04NonSkid' translation='0 15.56 -55.9'>
<Shape>
<Appearance>
<ImageTexture USE='NONSKID'/>
</Appearance>
<Extrusion creaseAngle='.85' crossSection='2.3 0 -2.3 0 -2.3 -.01 2.3 -.01 2.3 0' scale='.84 1 1 1' spine='0 0 0 0 0 -14.2'/>
</Shape>
</Transform>
<Transform translation='0 17.25 -58'>
<Inline USE='SPG-62MissileDirector'/>
</Transform>
</Group>
<Group DEF='AFT05'>
<Transform>
<Transform DEF='Aft05Aft' translation='0 15.55 -62'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion crossSection='-2.1 0 -1.9 1.5 1.9 1.5 2.1 0 -2.1 0' scale='1 .0001 1 1' spine='0 0 0 0 0 -.2'/>
</Shape>
</Transform>
<Transform DEF='Aft05FWD' translation='0 15.55 -69.80'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion ccw='false' crossSection='2.3 0 2.1 1.5 -2.1 1.5 -2.3 0 2.3 0' scale='1 1 1 .0001' spine='0 0 -0 0 0 -.3'/>
</Shape>
</Transform>
<Transform DEF='Aft05STBD' translation='0 15.55 -62'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion crossSection='2.1 0 2.1 1.5 2.3 0 2.1 0' scale='.91 .0001 .91 1 1 1 1 .0001' spine='0 0 0 0 0 -.2 0 0 -7.8 0 0 -8'/>
</Shape>
</Transform>
<Transform DEF='Aft05Port' translation='0 15.55 -62'>
<Shape>
<Appearance USE='HazeGray'/>
<Extrusion crossSection='-2.3 0 -2.1 1.5 -2.1 0 -2.3 0' scale='.91 .0001 .91 1 1 1 1 .0001' spine='0 0 0 0 0 -.2 0 0 -7.8 0 0 -8'/>
</Shape>
</Transform>
</Transform>
<Transform DEF='STACK' scale='.9 1 .9' translation='-1.15 17 -44.5'>
<Transform translation='1 -1 -21.4'>
<Shape>
<Appearance>
<Material DEF='STACKCOLOR' diffuseColor='.3 .3 .3'/>
</Appearance>
<Cylinder bottom='false' height='1.2' radius='1.3'/>
</Shape>
</Transform>
<Transform translation='1 0 -21.4'>
<Shape>
<Appearance>
<Material USE='STACKCOLOR'/>
</Appearance>
<Cylinder bottom='false' height='1.2' radius='1.5'/>
</Shape>
</Transform>
<Transform translation='1 .2 -21.4'>
<Shape>
<Appearance>
<Material USE='STACKCOLOR'/>
</Appearance>
<Cylinder bottom='false' height='1.2' radius='1.7'/>
</Shape>
</Transform>
</Transform>
<Transform translation='0 0 -4.25'>
<Transform USE='STACK'/>
</Transform>
<Transform scale='.5 1 .5' translation='1 0 -34'>
<Transform USE='STACK'/>
</Transform>
</Group>
</Group>
</Scene>
</X3D>
<!--

Index for DEF nodes : AFT01, Aft01AftAdjointoHanger, Aft01AftAdjoinToHangerNonSkid, Aft01NonSkid, AFT02, Aft02NonSkid, AFT03, Aft03NonSkid, AFT04, Aft04NonSkid, AFT05, Aft05Aft, Aft05FWD, Aft05Port, Aft05STBD, HazeGray, NONSKID, SPG-62MissileDirector, STACK, STACKCOLOR, SuperstructureAft
-->
