<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "http://www.web3d.org/specifications/x3d-3.0.dtd">
<X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' http://www.web3d.org/specifications/x3d-3.0.xsd '>
<head>
<meta name='title' content='FlightDeck.x3d'/>
<meta name='description' content='Arleigh Burke flight deck.'/>
<meta name='creator' content='James Harney'/>
<meta name='created' content='1 August 2001'/>
<meta name='modified' content='14 January 2014'/>
<meta name='reference' content='http:www.fas.org/man/dod-101/sys/ship/ddg-51.htm'/>
<meta name='reference' content='FASDDG51.htm'/>
<meta name='reference' content=' http://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Chapter18-TextureMapping/Figure18.23bTextureCoordinateGrillwork.x3d '/>
<meta name='reference' content='grillwork.png'/>
<meta name='identifier' content=' https://savage.nps.edu/Savage/ShipsMilitary/DDG-ArleighBurke-UnitedStates/FlightDeck.x3d '/>
<meta name='generator' content='X3D-Edit 3.2, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../../license.html'/>
</head>
<!--
Index for DEF nodes : ENTIRENET, FDNETBACK, FDNETRIGHT, FLIGHTDECK, FLTDECK, NETGREY, NETTING, NONSKID, POST, Screen, SIDEPOST, WHIPS
-->
<Scene>
<NavigationInfo/>
<LOD range='400'>
<Transform translation='0 -10 0'>
<Group DEF='FLIGHTDECK'>
<Transform translation='0 5.4 0'>
<Transform DEF='WHIPS' translation='-6.25 0 4'>
<Transform translation='.5 2 0'>
<Shape>
<Appearance>
<Material diffuseColor='.7 .7 .7' shininess='.3'/>
</Appearance>
<Cylinder height='3' radius='.15'/>
</Shape>
</Transform>
<Transform translation='-.5 2 0'>
<Shape>
<Appearance>
<Material diffuseColor='.7 .7 .7' shininess='.3'/>
</Appearance>
<Cylinder height='3' radius='.15'/>
</Shape>
</Transform>
<Transform rotation='0 0 1 1.56' translation='0 .5 0'>
<Shape>
<Appearance>
<Material diffuseColor='.7 .7 .7' shininess='.3'/>
</Appearance>
<Cylinder height='1' radius='.15'/>
</Shape>
</Transform>
<Transform translation='0 .25 0'>
<Shape>
<Appearance>
<Material diffuseColor='.7 .7 .7' shininess='.3'/>
</Appearance>
<Cylinder height='.5' radius='.15'/>
</Shape>
</Transform>
</Transform>
<Shape>
<Appearance>
<ImageTexture DEF='FLTDECK'
  url=' "nsflightdeck.jpg" "https://savage.nps.edu/Savage/DestroyerGuidedMissile-UnitedStates-ArleighBurke/nsflightdeck.jpg" '/>
</Appearance>
<IndexedFaceSet solid='false' coordIndex='2 3 0 1' texCoordIndex='3 2 1 0'>
<Coordinate point='7.5 .05 4.2 -7.5 .05 4.2 -9.375 .05 -24.1 9.375 .05 -24.1'/>
<TextureCoordinate point='1 0 1 1 0 1 0 0'/>
</IndexedFaceSet>
</Shape>
<Shape>
<Appearance>
<ImageTexture DEF='NONSKID'
  url=' "nonskid.jpg" "https://savage.nps.edu/Savage/DestroyerGuidedMissile-UnitedStates-ArleighBurke/nonskid.jpg" '/>
</Appearance>
<IndexedFaceSet solid='false' coordIndex='0 1 3 2 0 -1 5 7 6 4 5 -1 5 1 0 4 5 -1 0 4 6 2 0 -1 1 5 2 3 1 -1'>
<Coordinate point='7.5 0 4.2 -7.5 0 4.2 7.5 .05 4.2 -7.5 .05 4.2 9.375 0 -24.1 -9.375 0 -24.1 9.375 .05 -24.1 -9.375 .05 -24.1'/>
</IndexedFaceSet>
</Shape>
<Group DEF='FDNETBACK'>
<Transform>
<Group DEF='ENTIRENET'>
<Transform translation='2 .6 4.25'>
<Shape DEF='NETTING'>
<!-- GRILLWORK EXAMPLE FROM VRML COURSE BOOK USED -->
<Appearance>
<ImageTexture
  url=' "grill.png" "http://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Chapter18-TextureMapping/grill.png" '/>
<TextureTransform center='0.5 0.5' scale='32 8'/>
</Appearance>
<IndexedFaceSet DEF='Screen' solid='false' coordIndex='0 1 2 3' texCoordIndex='0 1 2 3'>
<Coordinate point='-1 -.4 0.1 1 -.4 0.1 1 .4 0.1 -1 .4 0.1'/>
<TextureCoordinate point='0 0 1 0 1 1 0 1'/>
</IndexedFaceSet>
</Shape>
<Transform translation='-1 0 0'>
<Shape DEF='POST'>
<Appearance DEF='NETGREY'>
<Material diffuseColor='.7 .7 .7' shininess='.3'/>
</Appearance>
<Cylinder DEF='SIDEPOST' height='1' radius='.1'/>
</Shape>
</Transform>
<Transform translation='1 0 0'>
<Shape USE='POST'/>
</Transform>
<Transform rotation='0 0 1 1.57' scale='1 2 1' translation='0 .4 0'>
<Shape USE='POST'/>
</Transform>
<Transform rotation='0 0 1 1.57' scale='1 2 1' translation='0 -.4 0'>
<Shape USE='POST'/>
</Transform>
</Transform>
</Group>
<Transform translation='2 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
<Transform translation='4 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
<Transform translation='-2 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
<Transform translation='-4 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
<Transform translation='-6 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
</Transform>
</Group>
<Group DEF='FDNETRIGHT'>
<Transform rotation='0 1 0 1.5' translation='3.45 0 -1.1'>
<Group USE='FDNETBACK'/>
</Transform>
<Transform rotation='0 1 0 1.5' translation='4.25 0 -13.1'>
<Group USE='FDNETBACK'/>
<Transform translation='6 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
<Transform translation='8 0 0'>
<Group USE='ENTIRENET'/>
</Transform>
</Transform>
</Group>
<Transform rotation='0 1 0 .14' translation='-15.25 0 1'>
<Group USE='FDNETRIGHT'/>
</Transform>
</Transform>
</Group>
</Transform>
<Transform translation='0 -10 0'>
<Transform translation='0 5.4 0'>
<Shape>
<Appearance>
<ImageTexture USE='NONSKID'/>
</Appearance>
<Extrusion creaseAngle='.85' crossSection='7.5 0 -7.5 0 -7.5 .5 7.5 .5 7.5 0' scale='1 .1 1 .1 1 .1 1.25 .1' spine='0 0 4.2 0 0 3 0 0 2 0 0 -24.1'/>
</Shape>
</Transform>
</Transform>
</LOD>
</Scene>
</X3D>
<!--
